PControl V2.1 - Build Instructions

PControl V2.1 - Build Instructions

1.0.0 - 8 September, 2015 2.27 MB

Build your own Pedalboard Controller using our modular system !

This is Revision 2.1 with several enhancements

  • processor controlled
  • easy-to-read display
  • 30 banks of 4 patches each
  • 8 Loops with optional Bi-Amping
  • Input board with linear driver and Tuner-Out
  • Up to 16 loops using the extension board
  • Input board has an optional power distribution area (recommended for the 16 loop version)
  • Software now allows to use manual mode which enables you to switch on/off single loops at will without the need for programming.

Based on your needs you are free to use the available components in building your own straight-to-the-point pedal controller unit!

Demonstration video of the unit:

The pedal controller 2.1 DIY-Set consists of:

  • 1 PControl 2.0 Display PCB
  • 1 PControl 2.1 Controller PCB
  • 1 PControl 2.0/3.0 Relais 1 PCB
  • 1 PControl 2.0/3.0 Relais 2 PCB
  • 1 PControl V3.0 Input/Tuner PCB
  • Programmed Microcontroller V2.12

For your reference the V2.0 build instructions:


PControl V2.1 has been discontinued. Please look out for the new PControl Modular Unit.
