DIY

Digital-FX V1.0 – DIY

Posted on 23 October, 201323 October, 2013 by TH custom effects

23
Oct

[wpdm_file id=37] TH custom effects brings Digtal-FX to the DIY-community! I came across this great little module featuring 16 modulation effects and had the urge to use it for pedal building. Here is what I came up with. A versatile stomp box with 16 digital effects. Easy to use and easy to build. Fits minimum […]

Continue reading →

DIY, slideshow

Acoustic Simulator V1.0/V1.1 – DIY

Posted on 11 September, 201317 September, 2015 by TH custom effects

11
Sep

Version 1.1: [wpdm_file id=48] Version 1.0: [wpdm_file id=35] Cool, what does it do? It enables you to play acoustic guitar on your gig without taking one with you. This circuit is known as Mark Hammers “Woody” and well recognized in the DIY area. Version 1.1 has a new layout which includes additional filter caps.

Continue reading →

The Ultimate Switch V2.0 – DIY

Posted on 11 September, 20137 June, 2015 by TH custom effects

11
Sep

[wpdm_file id=34] The ultimate switch developed out of the need to somehow bring back old times when you had switches (more than 1) that released any already pressed switch when a new switch is pressed. You would call that a 1 out of X logic or radiobuttons if you were in the microprocessor area. During […]

Continue reading →

DIY, slideshow

5-Band Equalizer – DIY

Posted on 5 September, 201323 November, 2015 by TH custom effects

05
Sep

This is a subminiature equalizer where you are able to define the frequency bands YOU need. It will fit a 1590B from side to side. As this circuit features a special chip which is not easy to source you can also order the chip together with the board! Here is a drill template: [wpdm_file id=51] […]

Continue reading →

DIY, slideshow

10W Power Amp V1.1 – DIY

Posted on 29 August, 2013 by TH custom effects

29
Aug

[wpdm_file id=32] A slimline solid state amplifier that provides up to 10W and runs on a 9V or 12V supply. This small beast offers a Hi-Fi quality solid state amp for almost any usage you can imagine. Be it a spare amp for your pedalboard or and external amp to party with your iPod! I […]

Continue reading →

DIY, slideshow

All-in-One Recording/OnStage Unit- DIY

Posted on 29 August, 201330 August, 2013 by TH custom effects

29
Aug

[wpdm_file id=31] The All-In-One box is a the core part to your universal tool for recording, home-practicing and stage. What does it do? Input gain control FX Loop Wet/Dry Mixer (it’s a panner actually, so you can have 100% wet and 0% dry) aux in and aux volume control (connect your favourite mp3 player) buffered […]

Continue reading →

DIY, slideshow

Tubescreamer(R) mini – DIY

Posted on 21 August, 201315 January, 2014 by TH custom effects

21
Aug

[wpdm_file id=40] Here is the miniature version of a TS. This version includes a lot of modifications to the orginal circuit and just sounds great! For your reference here are the previous build instructions: [wpdm_file id=28]

Continue reading →

DIY, slideshow

Valv-e-tizer 1.1/1.3/1.4/1.5 – DIY

Posted on 13 June, 201328 September, 2015 by TH custom effects

13
Jun

[wpdm_file id=45] [wpdm_file id=26] [wpdm_file id=25] [wpdm_file id=4] Did you ever want to build a real tube pedal but you have been embarassed by the disadvantages: high, lethal voltage free wiring all the irritating schematics then this is for you. Valv-e-tizer is a project running on 9V pedal power builds like any other effect circuit […]

Continue reading →

DIY

MadBox – Mixer/Splitter V1.0 – DIY

Posted on 13 June, 201322 August, 2013 by TH custom effects

13
Jun

[wpdm_file id=24] The MadBox is a stripped Pro-cessor. Without the filter stages you can use it as a Paralooper or only the Mixing or the Splitter parts of it.

Continue reading →

DIY

OD 66 – DIY

Posted on 29 May, 201311 August, 2015 by TH custom effects

29
May

[wpdm_file id=19] The OD 66 Overdrive is based on the old DOD 250(TM) Overdrive. This version features an additional switch for the selection of different clipping diodes. This build is easy for beginners and fits a 1590B enclosure easily. [wpdm_file id=20] The V1.1 version features the 9mm helper pot, better aligned Pads and an […]

Continue reading →
